Lowrance HDS PRO 16 No sonar transducer

Lowrance HDS-16 PRO – The Ultimate Sonar and Chart Plotter

The Lowrance HDS-16 PRO is the most advanced unit in the HDS PRO series, designed to give anglers a superior fishing experience. Even without an included transducer, this unit is ready for ActiveTarget® 2 Live sonar, giving you real-time images of how the fish are reacting to your bait. With 1.2 MHz Active Imaging™ HD support, you get extremely high-resolution images of fish and underwater structures through Lowrance CHIRP, SideScan and DownScan Imaging™.

The impressive 16-inch SolarMAX™ HD touchscreen provides a clear and crisp image, even in strong sunlight or through polarized sunglasses. Thanks to the large screen, you can easily manage multiple information panels at the same time, making it easy to find fish, analyze structures and navigate.

The HDS-16 PRO comes with a global base map, but can be upgraded with charts from C-MAP® DISCOVER, REVEAL and other providers. In addition, you can create your own maps in real time with C-MAP Genesis Live, which helps you map fishing areas directly on the water. The device also supports the ActiveTarget® scout view and Ghost® trolling engine 360, providing a comprehensive view of the underwater environment.

With NMEA 2000®, Bluetooth® and wireless connection, you can control the boat's entire system directly from the touch screen. It includes Power-Pole® anchor, Ghost® trolling motor, autopilot and Lowrance Outboard Pilot. In addition, the unit has large programmable buttons, so you can tailor functions to your specific needs, making it a versatile and user-friendly solution for all anglers.

Main functions:

✅ ActiveTarget® 2 Live Sonar – See fish movements in real time
​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​​ fish identification
✅ NMEA 2000® and Bluetooth® connectivity – Full control of the boat's systems
✅ C-MAP Genesis Live – Create detailed maps in real time
✅ Compatible with Ghost® trolling engine 360 – Provides a complete view of the underwater environment
✅ Large programmable buttons – Customize functions according to your fishing

Specifications:

• Screen size: 16 inches
• Dimensions: 430.5 mm x 259.2 mm x 87.8 mm
• Voltage: 12V DC (10.8-17V DC)
• Power consumption: Max 4.1A @ 13V DC with full brightness and sonar active
• Mount Type: Gimbal Bracket, Front Dash Flush Mount, Rear Dash Flush Mount

What is included in the package:

• PC-30-RS422 power cable for HDS series
• HDS connection cover
• HDS-16 LIVE sunscreen
• HDS-16 LIVE bracket
